Steel Factory Battery Operated Motorized Transport Vehicle to Molds Dies Transfer

Name: Steel Factory Battery Operated Motorized Transport Vehicle to Molds Dies Transfer
Brand: Topleader
Price: 6000 USD

Quality Steel Factory Battery Operated Motorized Transport Vehicle to Molds Dies Transfer wholesale

Brand Name : Topleader

Model Number : KPX

Certification : CE,ISO9000

Place of Origin : China

MOQ : 1 set

Price : $6000

Payment Terms : L/C, T/T, Western Union

Supply Ability : 600 sets/year

Delivery Time : 40 days after your prepayment

Packaging Details : The whole Motorized Transport Vehicle to Molds Dies Transfer will be packed by the tarp, the parts will be packed by polywood case.

Product name : Steel Factory Battery Operated Motorized Transport Vehicle to Molds Dies Transfer

Power supply : Battery Operated

Key Words : Motorized Transport Vehicle to Molds Dies Transfer

Load capacity : 1-500T

Running speed : 20m/min

Application : inplant, production line

Warranty : 1 year

Color : customized

OEM : Accepted

Contact Now

Steel Factory Battery Operated Motorized Transport Vehicle to Molds Dies Transfer

Product Introduce - - - Motorized Transport Vehicle To Molds Dies Transfer

The battery operated motorized transport vehicle offers a wide range of mold dies transfer specifically designed for the unique needs of both stamping and molding. It also can be called Die Transport Equipment, Die Cart, Die Transfer Trolleys and Die Trailers Systems, etc.
This motorized transport vehicle tp molds dies transfer could run on railways or cement floor which is chosen according to the transportation route or clients' project plan. The selecting concept: the rail transport vehicle is mainly used for fixed route no need of rotation; while the trackless transfer vehicle on cement floor can realize 360° direction turning.

Advantage - - - Motorized Transport Vehicle To Molds Dies Transfer

Safe and environment friendly

Big starting power

Small impact to the gear reducer

No restriction of the running distance

Can running on s-shape rail, arc-shape rails

Has no limit on working distance

Anti-explosion, anti-high temperature

Stable start, big starting power, long lifetime.

Technical Parameters - - - Motorized Transport Vehicle To Molds Dies Transfer

Rated load (T)		2	10	20	30	50	80	100
Table size	length(L)	2000	2300	2400	3500	5500	6500	6600
	Width(W)	1500	2000	2200	2200	2600	2800	3000
	Height(H)	450	500	600	700	800	950	1200
Wheel Base (mm)		1080	1650	2800	1650	2000	1950	2000
Axle Base (mm)		1380	1850	1435	2700	2850	3500	4000
Wheel Diameter(mm)		Φ250	Φ400	Φ350	Φ450	Φ600	Φ600	Φ600
Wheel Quantity(Nos)		4	4	4	4	4	4	8
Ground Clearance (mm)		50	50	50	50	50	75	75
Running speed (m/min)		0-25	0-25	0-20	0-20	0-20	0-20	0-18
Motor Power (Kw)		2*1.2	2*2.2	2*4.5	2*5.5	2*7.5	30	40
Battery Capacity(Ah)		250	250	400	450	500	800	1000
Battery Voltage(V)		24	48	48	48	72	72	72
Running Time When Full Load		2.5	2.8	2.2	2	2.5	2	1.9
Running Distance for one Charge(Km)		3	3.4	2.7	2.4	3	32.4	2.3

Application - - - Motorized Transport Vehicle To Molds Dies Transfer

The battery operated motorized transport vehicle to molds dies transfer allow movement charges at ground level in all types of industries and applications, such as warehouse, within or without factory, bay to bay, airport, sea port, manufacturing workshop, production line and son on.

Parts Show - - - Motorized Transport Vehicle To Molds Dies Transfer

Packing & Delivery - - - Motorized Transport Vehicle To Molds Dies Transfer

Packing Details : The whole battery operated motorized transport vehicle is packed by the tarp, the parts will be packed by polywood case
Delivery Details : 3-30 days after order of Solid bicycle tire tubes

Steel Factory Battery Operated Motorized Transport Vehicle to Molds Dies Transfer

Customers

Our After Service

Our commitment:
The load bearing safety factor of the vehicle is no less than 120%;
Freely design the auxiliary device or foundation drawing, and offer the technical service and drawing material
16 hours engineering service and 24 hours internet service for our customers;
During the warranty period, if our products can't work normally, we can support you repair technology or replace relevant parts for you within 24 hours;
Solving the quality problem within 24 hours, serious attitude from beginning to end.Value the reputation and Preserve the image of our company.

Q & A: How to choose ?

Please provide the answers below:
-Load capacity?
-Table size? (Length; Width ; Height)
-What cargo do you use the cart to transfer?
-What is the travel area you need to cover? (Indoor/Outdoor, straight line travel, etc)
-How about the running distance?
-What type(s) of power supply are required?
-Do you need any special functions?

tags:rail powered transport truck,railway powered transport truck
